EDX-880 Gold Purity Spectrum Analyser

Send Inquiry

Product Code : EDX-880

Brand Name : Redlands

Product Specifications

Usage
Gold Element Analyser
Machine Weight
39 Kilograms (kg)

Dimensions
450mm x 450mm x 360mm / 300mm X 250mm X 160mm (Sample Chamber) Millimeter (mm)
Power
230V , 50Hz Watt/Volt ( w/v)

Product Description

EDX-880 Gold Purity Spectrum Analyser is most commonly utilized in metal testing laboratories and jewelry showrooms for detecting purity level of precious ornaments. It is known to work on principle of using gas filled proportional counter that work in accordance with a specific software for delivering accurate results. This analyzer is highly appreciated for having short detection time of up to 300 seconds and assures highly accurate results. It has compact structural configuration hence does not require much installation space. EDX-880 Gold Purity Spectrum Analyser has ability to detect multiple metals present in sample with their percentage.

Product Details:

Minimum Order Quantity	1 Number
Color	Silver
Brand	REDLANDS
Model	EDX-880
Application	Industrial Use,Laboratory Use
Weight	39 Kg
Measurment Time	30 - 300 seconds
Measurement Range	1 - 99.99 %

Technical Specifications

X-ray Source	X-ray Tube Ti or W cathode
HV Generator	50kv adjustable in 200V steps Current adjustable in 1mA steps
Detector	Gas filled proportional counter
Detection	Range Au, Ag, Pt, Pd, Rh, Ru, Cu, Cd, Zn, Ni
Measurement Range	1 - 99.99 %
Measurement Time	30 - 300 seconds
Measurement Precision	Â± 0.1% - In homogeneously melted sample
( Accuracy levels in comparison with fire assay result only )
Measurement Area	1 mm
Working Temperature	15 - 250C
Relative Humidity	10 - 80%
System Requirement External PC with Windows XP or Windows 7(32bit)
Software	Windows Based
Power Requirement	230V , 50Hz
Power Consumption	70W
Dimension	450mm x 450mm x 360mm
Sample Chamber	300mm X 250mm X 160mm
Weight	39 Kg
